350PSI Grooved Swing Check Valve

Grooved End

Technical Features:

Nominal Pressure: 350PSI
Groove standard : AWWA C606
Sizes: 2", 2½", 3", 4", 5", 6", 8", 10", 12"
Approvals: UL, FM
Maximum Working Pressure: 350PSI (Maximum Testing Pressure: 700 PSI) conforms to UL 312 & FM class 1210
Maximum Working Temperature: 80°C / 176°F
Coating Details: Epoxy coated interior and exterior by Electrostatic Spray or coating upon request
Applications: Used in one-way flow pipeline to prevent the water from back flow
